Product details
A black electro-coat finish distinguishes this left-hand 12.88-inch GT rotor from the uncoated version. Under the finish is the same slotted Spec-37 architecture, with 48 curved vanes and a 1.25-inch nominal thickness. System compatibility is central to choosing a replacement rotor, including its relationship to the caliper, pad and mounting hardware. Wilwood designs and manufactures disc brake systems in Camarillo, California, offering calipers, rotors, master cylinders, valves, fittings and lines across motorsport, street performance and specialized applications. The company was founded in 1977 by Bill Wood.
Technical Details
- Manufacturer part number: 160-4565-GTB
- Quantity: One rotor; not an axle pair
- Outside diameter: 12.88 inches
- Nominal thickness: 1.25 inches
- Rotor material: Spec-37 Iron
- Construction: 48 curved vanes
- Friction surface: GT Slotted
- Finish: Black Electro Coat
- Approximate weight: 11.70 lb
- Factory burnished: No
- Dynamically balanced: Yes
- Installation orientation: Left-hand
- Rotor attachment pattern: 12 x 8.75 inches
- Rotor mounting hole / thread: 0.251 inches
- Registration / lug inside diameter: 8.25 inches
- Far-side inside diameter: 9.46 inches
- Opposite-hand companion rotor: 160-4564-GTB (sold separately)
- Intended use and restrictions: Suitable for moderate-temperature racing and street use. Spec-37 heavy-wall castings.
The hat or hub, fasteners, caliper and pads are not included.
Fitment & Compatibility
Check the twelve-hole connection and 8.25-inch center register against the installed hat. Coating is not a substitute for the specified brake preparation or a different rotor size.
Wilwood product specifications · Rotor dimension diagram
For more than 20 years, PMB Performance has helped customers choose brake components. Share the details of your current setup for assistance with rotor selection.
