Product details
This black electro-coated version retains the 12.88 x 1.25-inch geometry of the right-hand GT rotor. The protective treatment accompanies a slotted Spec-37 ring with 48 curved vanes, rather than changing its mounting dimensions or supplied burnish condition. Camarillo, California is home to Wilwood, founded by Bill Wood in 1977. The company designs and manufactures disc brake systems for motorsport, street performance and specialized applications, supplying rotors, calipers, master cylinders, valves, fittings and lines. Matching the rotor to the complete assembly matters as much as selecting its diameter or surface treatment.
Technical Details
- Manufacturer part number: 160-4564-GTB
- Quantity: One rotor; not an axle pair
- Outside diameter: 12.88 inches
- Nominal thickness: 1.25 inches
- Rotor material: Spec-37 Iron
- Construction: 48 curved vanes
- Friction surface: GT Slotted
- Finish: Black Electro Coat
- Approximate weight: 11.70 lb
- Factory burnished: No
- Dynamically balanced: Yes
- Installation orientation: Right-hand
- Rotor attachment pattern: 12 x 8.75 inches
- Rotor mounting hole / thread: 0.251 inches
- Registration / lug inside diameter: 8.25 inches
- Far-side inside diameter: 9.46 inches
- Opposite-hand companion rotor: 160-4565-GTB (sold separately)
- Intended use and restrictions: Suitable for moderate-temperature racing and street use. Spec-37 heavy-wall castings.
The hat or hub, fasteners, caliper and pads are not included.
Fitment & Compatibility
Use the matching 8.75-inch twelve-hole hat flange and 8.25-inch register. The caliper and hardware remain those specified for the complete 12.88-inch brake assembly.
Wilwood product specifications · Rotor dimension diagram
