Product details
Left-hand cooling vanes establish the installation side of this 13.06-inch GT casting. Its slotted faces and thick Spec-37 friction section are carried by an eight-hole mounting flange, giving it different hardware requirements from the narrower twelve-bolt versions. Founded by Bill Wood in 1977, Wilwood designs and manufactures disc brake systems in Camarillo, California. Its range includes calipers, rotors, master cylinders, valves, fittings and lines for motorsport, street performance and specialized applications. Rotor choice belongs within that complete system: the caliper, pad, mounting hardware and intended duty must work together.
Technical Details
- Manufacturer part number: 160-3585
- Quantity: One rotor; not an axle pair
- Outside diameter: 13.06 inches
- Nominal thickness: 1.38 inches
- Rotor material: Spec-37 Iron
- Construction: 48 curved vanes
- Friction surface: GT Slotted
- Finish: Plain
- Approximate weight: 16.00 lb
- Factory burnished: No
- Dynamically balanced: Yes
- Installation orientation: Left-hand
- Rotor attachment pattern: 8 x 7.00 inches
- Rotor mounting hole / thread: 0.316 inches
- Registration / lug inside diameter: 6.53 inches
- Far-side inside diameter: 9.21 inches
- Opposite-hand companion rotor: 160-3584 (sold separately)
- Intended use and restrictions: Suitable for high-temperature racing and street use. Spec-37 heavy-wall castings.
The hat or hub, fasteners, caliper and pads are not included.
Fitment & Compatibility
Check the 7.00-inch rotor circle and 6.53-inch registration diameter. The caliper must accommodate the full 1.38-inch nominal thickness.
Wilwood product specifications · Rotor dimension diagram
PMB Performance brings more than 20 years of brake expertise to component selection. Contact us with your existing rotor and brake-package details if you need help checking the match.
