Product details
A 1.38-inch friction section and compact twelve-hole flange distinguish this 12.72-inch GT rotor. The right-hand Spec-37 casting uses 48 curved vanes and slotted contact faces, with the mounting ring concentrated around a 6.25-inch center register. Founded by Bill Wood in 1977, Wilwood designs and manufactures disc brake systems in Camarillo, California. Its range includes calipers, rotors, master cylinders, valves, fittings and lines for motorsport, street performance and specialized applications. Rotor choice belongs within that complete system: the caliper, pad, mounting hardware and intended duty must work together.
Technical Details
- Manufacturer part number: 160-3314
- Quantity: One rotor; not an axle pair
- Outside diameter: 12.72 inches
- Nominal thickness: 1.38 inches
- Rotor material: Spec-37 Iron
- Construction: 48 curved vanes
- Friction surface: GT Slotted
- Finish: Plain
- Approximate weight: 18.70 lb
- Factory burnished: No
- Dynamically balanced: Yes
- Installation orientation: Right-hand
- Rotor attachment pattern: 12 x 6.75 inches
- Rotor mounting hole / thread: 0.251 inches
- Registration / lug inside diameter: 6.25 inches
- Far-side inside diameter: 7.69 inches
- Opposite-hand companion rotor: 160-3315 (sold separately)
- Intended use and restrictions: Suitable for moderate-temperature racing and street use. Spec-37 heavy-wall castings.
The hat or hub, fasteners, caliper and pads are not included.
Fitment & Compatibility
Match the 6.75-inch attachment circle and 0.251-inch holes to the intended hat. Confirm the thicker rotor section and right-side orientation before selection.
