Product details
For the left side of the specified 13.50-inch rear conversion, this SRP rotor supplies the corresponding face orientation. The straight-vane iron core does not itself dictate rotation, so the kit’s left/right component assignment is the useful replacement reference. System compatibility is central to choosing a replacement rotor, including its relationship to the caliper, pad and mounting hardware. Wilwood designs and manufactures disc brake systems in Camarillo, California, offering calipers, rotors, master cylinders, valves, fittings and lines across motorsport, street performance and specialized applications. The company was founded in 1977 by Bill Wood.
Technical Details
- Manufacturer part number: 160-18051-BK
- Quantity: One rotor; not an axle pair
- Outside diameter: 13.50 inches
- Nominal thickness: 0.81 inches
- Rotor material: Iron
- Construction: 36 vanes
- Friction surface: SRP Drilled & Slotted
- Finish: Black Electro Coat
- Approximate weight: 12.50 lb
- Factory burnished: No
- Dynamically balanced: Yes
- Installation orientation: Left-hand in the specified rear kits; 36 straight vanes
- Rotor attachment pattern: 12 x 8.75 inches
- Rotor mounting hole / thread: 0.251 inches
- Registration / lug inside diameter: 8.25 inches
- Far-side inside diameter: 9.50 inches
- Opposite-hand companion rotor: 160-18050-BK (sold separately)
The hat or hub, fasteners, caliper and pads are not included.
Fitment & Compatibility
Verify the installed Wilwood rear kit and its 0.81-inch rotor specification. The 8.75-inch attachment circle connects to a separate hat and does not describe wheel fitment.
Wilwood product specifications · Rotor dimension diagram
