Product details
This right-hand SRP rotor provides an 11.38-inch diameter where the brake package calls for a smaller ring than the familiar 11.75-inch size. Its 36 curved vanes and drilled-and-slotted faces require the specified orientation within a matched assembly. Founded by Bill Wood in 1977, Wilwood designs and manufactures disc brake systems in Camarillo, California. Its range includes calipers, rotors, master cylinders, valves, fittings and lines for motorsport, street performance and specialized applications. Rotor choice belongs within that complete system: the caliper, pad, mounting hardware and intended duty must work together.
Technical Details
- Manufacturer part number: 160-17484-BK
- Quantity: One rotor; not an axle pair
- Outside diameter: 11.38 inches
- Nominal thickness: 0.81 inches
- Rotor material: Iron
- Construction: 36 curved vanes
- Friction surface: SRP Drilled & Slotted
- Finish: Black Electro Coat
- Approximate weight: 8.50 lb
- Factory burnished: No
- Dynamically balanced: No
- Installation orientation: Right-hand
- Rotor attachment pattern: 8 x 7.00 inches
- Rotor mounting hole / thread: 0.326 inches
- Registration / lug inside diameter: 6.38 inches
- Far-side inside diameter: 7.87 inches
- Opposite-hand companion rotor: 160-17485-BK (sold separately)
The hat or hub, fasteners, caliper and pads are not included.
Fitment & Compatibility
Confirm the 0.81-inch caliper width, 6.38-inch register and 0.326-inch mounting holes. The eight-bolt circle describes rotor attachment, not wheel fitment.
Wilwood product specifications · Rotor dimension diagram
PMB Performance brings more than 20 years of brake expertise to component selection. Contact us with your existing rotor and brake-package details if you need help checking the match.
