Product details
A left-hand SRP face pattern and an integral 0.720-inch-offset hat identify this Jeep front-package replacement. Its vented 13.38-inch ring must be used with the caliper and mounting geometry specified for the matching AERO6-DM installation. Camarillo, California is home to Wilwood, founded by Bill Wood in 1977. The company designs and manufactures disc brake systems for motorsport, street performance and specialized applications, supplying rotors, calipers, master cylinders, valves, fittings and lines. Matching the rotor to the complete assembly matters as much as selecting its diameter or surface treatment.
Technical Details
- Manufacturer part number: 160-16966-BK
- Quantity: One rotor; not an axle pair
- Outside diameter: 13.38 inches
- Nominal thickness: 1.25 inches
- Rotor material: Iron
- Construction: 48 vanes
- Friction surface: SRP Drilled & Slotted
- Finish: Black Electro Coat
- Approximate weight: 26.63 lb
- Factory burnished: No
- Dynamically balanced: Yes
- Installation orientation: Left-hand
- Registration / lug inside diameter: 2.84 inches
- Far-side inside diameter: 9.28 inches
- Rotor offset: 0.720 inches
- Internal clearance diameter: 7.30 inches
- Mounting-face thickness: 0.24 inches
- Hat wheel-stud clearance pattern: 5 x 5.00 inches
- Wheel-stud clearance hole diameter: 0.64 inches
- Opposite-hand companion rotor: 160-16965-BK (sold separately)
The integral hat is part of the rotor; caliper, pads, parking-brake mechanism and installation hardware are separate.
Fitment & Compatibility
Check the exact kit application under DS1550 and confirm the 2.84-inch registration bore. The five-stud drilling provides clearance through the rotor without altering the vehicle hub pattern.
Wilwood product specifications · Rotor dimension diagram · Installation reference DS1550
