Product details
The left factory-burnished GT ring retains the 13.06-inch diameter and 1.25-inch working width. Its slotted Spec-37 friction surface and larger dynamic-lug interface are selected together for the matching race or street brake arrangement. Wilwood Engineering, established by Bill Wood in 1977 and based in Camarillo, California, designs and manufactures disc brake systems. Its component range spans brake rotors and calipers alongside master cylinders, valves, fittings and brake lines for motorsport, street-performance and specialized applications. The complete brake system governs which components belong together.
Technical Details
- Manufacturer part number: 160-15872-B
- Rotor size: 13.06 inches diameter x 1.25 inches wide
- Rotor material: Spec-37 Iron
- Face and finish: GT Slotted; Plain
- Vanes: 48 CV; curved
- Mounting direction: Left-hand
- Factory condition: Factory burnished yes; balanced yes
- Opposite-side component, ordered separately: 160-15871-B
- Dynamic-lug mounting interface: 12 x 8.80 inches
- Mounting interface: Lug
- Center / lug registration: 8.12 inches
- Far-side inside diameter: 9.46 inches
- Approximate component weight: 12.95 lb
- Quantity: one rotor ring; hat, hub, mounting hardware, calipers and pads are separate
Fitment & Compatibility
Requires the specified dynamic-lug hat or carrier and its retaining hardware. The lugs accommodate the intended mounting movement; conventional bolt-hole hats are not interchangeable. Check the rotor's diameter, working width and registration against the complete caliper assembly. The listed duty is street use through moderate-temperature competition.
Manufacturer reference: Wilwood rotor specifications
Contact PMB Performance with the rotor and brake-system details for fitment assistance informed by more than 20 years of experience.
