Wilwood Rear Toyota LC70 Black GTB Rotor, 12.88 x 1.25-inch, Integral Hat

This 12.88-inch rear GTB rotor is specified in Wilwood's matching LC70 rear conversion with a 1.25-inch friction width. Manufacturer listings disagree on the five-hole mounting circle, so the supplied component must be confirmed against the actual rear hub before ordering. Bill Wood established Wilwood Engineering in 1977; the company is based in Camarillo, California and designs and manufactures disc brake systems. Calipers, brake rotors, master cylinders, valves, fittings and brake lines form its range for motorsport, street-performance and specialized applications. Compatibility depends on selecting those parts for the requirements of the complete brake system.

Technical Details

• Manufacturer part number: 160-15758-GTB
• Diameter and thickness: 12.88 inches diameter x 1.25 inches wide
• Ring material: Iron
• Face pattern and coating: GT Slotted; Black electrocoat
• Internal layout: 42 vanes
• Mounting direction: Non-directional
• Balancing and burnishing: Factory burnished no; balanced yes
• Five-hole mounting circle: rotor page 5 x 5.669 inches; RotorList2 5 x 5.91 inches; confirmation required
• Center / lug registration: 4.34 inches
• Far-side inside diameter: 9.20 inches
• Hat offset: 1.655 inches
• Inside clearance diameter: 7.86 inches
• Approximate component weight: 19.47 lb
• Quantity: one rotor with integral hat; separate hub, pads, calipers, mounting hardware and any parking-brake mechanism are not included

Fitment & Compatibility

For the Toyota Land Cruiser LC70 rear conversion in DS-1552. Confirm the five-hole mounting circle against the supplied component: the individual rotor page says 5 x 5.669 inches, while Wilwood's RotorList2 lists 5 x 5.91 inches. Verify the 1.655-inch offset and 4.34-inch center with the complete rear kit before ordering.

Manufacturer reference: Wilwood rotor specifications, Installation document DS1552, Wilwood rotor range and dimensions
