Product details
The 1.52-inch offset places this right front SRP rotor's friction ring relative to its integral mounting face. Paired 4.75- and 5.00-inch five-lug clearance circles accommodate the matching hub for the 12.19 x 1.10-inch front brake conversion. This component comes from Wilwood Engineering, founded by Bill Wood in 1977 and based in Camarillo, California. Wilwood designs and manufactures disc brake systems, including calipers, brake rotors, master cylinders, valves, fittings and brake lines for motorsport, street-performance and specialized applications, with compatibility determined by the complete brake assembly.
Technical Details
- Manufacturer part number: 160-15513-BK
- Outside diameter / width: 12.19 inches diameter x 1.10 inches wide
- Material specification: Iron
- Friction surface / finish: SRP Drilled & Slotted; Black electrocoat
- Ventilation: 32 vanes
- Mounting direction: Right-hand
- Preparation: Balanced: yes; factory burnished: no
- Opposite-side component, ordered separately: 160-15514-BK
- Hat wheel-stud clearance pattern: 5 x 4.75/5.00 inches
- Stud clearance-hole sizes: 0.52 inches
- Center registration: 3.06 inches
- Far-side inside diameter: 8.34 inches
- Hat offset: 1.520 inches
- Inside clearance diameter: 7.11 inches
- Hat mounting-face thickness: 0.25 inches
- Approximate weight: 18.72 lb
- Quantity: one rotor with integral hat; separate hub, pads, calipers, mounting hardware and any parking-brake mechanism are not included
Fitment & Compatibility
Front replacement rotor for the matching 1963–1987 Chevrolet C10 conversion using the specified Wilwood ProSpindle and five-lug hub. DS-1365 requires the correct later ball joints for earlier trucks and later tie-rod ends for 1971–1972 applications. The 1.52-inch hat and dual clearance patterns do not make this a stock-spindle replacement.
Manufacturer reference: Wilwood rotor specifications, Installation document DS1365
For help identifying the correct replacement, share the installed brake package with PMB Performance. Our team draws on over 20 years of experience with brake components and fitment.
