Product details
This 14.50-inch rear GTB rotor serves the matching 2008–2018 Toyota LC200 conversion while retaining the original parking-brake arrangement. Its shallow 0.66-inch hat offset, five-on-150 mm stud clearances and 9.44-inch drum must suit the complete kit. Bill Wood founded Wilwood Engineering in 1977. Based in Camarillo, California, the company designs and manufactures disc brake systems, including calipers, brake rotors, master cylinders, valves, fittings and brake lines. Its motorsport, street-performance and specialized components are selected around the requirements of the whole braking system.
Technical Details
- Manufacturer part number: 160-15475-GTB
- Rotor size: 14.50 inches diameter x 1.10 inches wide
- Rotor material: Iron
- Face and finish: GT Slotted; Black electrocoat
- Vanes: 42 vanes
- Mounting direction: Non-directional
- Factory condition: Factory burnished no; balanced no
- Hat wheel-stud clearance pattern: 5 X 5.91 inches
- Stud clearance-hole sizes: 0.64 inches
- Center / lug registration: 4.42 inches
- Far-side inside diameter: 10.87 inches
- Hat offset: 0.660 inches
- Internal parking-drum diameter: 9.44 inches
- Inside clearance diameter: 7.91 inches
- Hat mounting-face thickness: 0.35 inches
- Approximate component weight: 27.80 lb
- Quantity: one rotor with integral hat; separate hub, pads, calipers, mounting hardware and any parking-brake mechanism are not included
Fitment & Compatibility
For the matched 2008–2015 Toyota LC200 rear kit in DS-1357 or the 2016–2018 kit in DS-1379, retaining the OE parking brake. These conversions require backing-plate/dust-shield and upright clearance modifications. Verify the five-on-150 mm hub, 0.66-inch offset and 9.44-inch internal drum; this rotor is not a complete conversion.
Manufacturer reference: Wilwood rotor specifications, Installation document DS1357, Installation document DS1379
With more than 20 years of parts and brake-system experience, PMB Performance can help review the rotor, hat and caliper combination before you order.
