Product details
This hub-and-rotor assembly serves the matching 1951–1959 Chevrolet half-ton front brake conversion. Its 11.86-inch friction ring is 1.10 inches wide, and the wheel hub provides two five-lug patterns for the correctly configured installation. Wilwood Engineering, established by Bill Wood in 1977 and based in Camarillo, California, designs and manufactures disc brake systems. Its component range spans brake rotors and calipers alongside master cylinders, valves, fittings and brake lines for motorsport, street-performance and specialized applications. The complete brake system governs which components belong together.
Technical Details
- Manufacturer part number: 160-14950
- Rotor size: 11.86 inches diameter x 1.10 inches wide
- Rotor material: Iron
- Face and finish: Plain Face; Plain
- Vanes: 36 vanes
- Mounting direction: Non-directional
- Factory condition: Factory burnished no; balanced no
- Hub wheel-stud pattern: 5 x 4.75/5.00 inches
- Wheel-stud nominal diameter: 0.5 inches
- Far-side inside diameter: 8.03 inches
- Approximate component weight: 30.00 lb
- Quantity: one integrated hub-and-rotor component; the complete brake conversion, calipers, pads and bearings are not supplied as a kit
Fitment & Compatibility
For the matching 1951–1959 Chevrolet half-ton pickup front conversion. The 1.10-inch rotor width, spindle bearings and caliper brackets must all agree with the kit, and the selected five-lug wheel pattern must suit the wheels. This is not a complete brake conversion.
Manufacturer reference: Wilwood rotor specifications
Contact PMB Performance with the rotor and brake-system details for fitment assistance informed by more than 20 years of experience.
