Wilwood Rear Right SRP Rotor for Corvette C5 1997–2004 and C6 Base 2005–2013

This right rear SRP rotor is the OE-dimension component for the specified C5 and base C6 Corvette brakes. Its face is dimpled and slotted rather than drilled through, with the internal parking drum cast into the hat. Based in Camarillo, California, Wilwood Engineering was founded in 1977 by Bill Wood to design and manufacture disc brake systems and components. Its calipers, brake rotors, master cylinders, valves, fittings and brake lines serve motorsport, street-performance and specialized applications. Rotor selection is therefore a decision about the whole brake system and its mating parts.

Technical Details

• Manufacturer part number: 160-14040-BK
• Rotor size: 12.01 inches diameter x 1.03 inches wide
• Rotor material: Iron
• Face and finish: SRP Dimpled & Slotted; Black electrocoat
• Vanes: Vented
• Mounting direction: Right-hand
• Factory condition: Factory burnished no; balanced no
• Opposite-side component, ordered separately: 160-14041-BK
• Hat wheel-stud clearance pattern: 5 x 4.75 inches
• Stud clearance-hole sizes: 0.52 inches
• Center / lug registration: 2.78 inches
• Far-side inside diameter: 8.80 inches
• Hat offset: 0.590 inches
• Internal parking-drum diameter: 7.48 inches
• Inside clearance diameter: 6.17 inches
• Hat mounting-face thickness: 0.25 inches
• Approximate component weight: 16.20 lb
• Quantity: one rotor with integral hat; separate hub, pads, calipers, mounting hardware and any parking-brake mechanism are not included

Fitment & Compatibility

For the original rear brake configuration on 1997–2004 Corvette C5 and 2005–2013 Corvette C6 base models. C6 Z06 and Z51 systems are excluded; other enlarged-brake configurations require their own rotor. Check the internal parking drum and OE hub dimensions. The dimpled face is not through-drilled.

Manufacturer reference: Wilwood rotor specifications, Installation document DS541

With more than 20 years of parts and brake-system experience, PMB Performance can help review the rotor, hat and caliper combination before you order.
