Product details
Straight vanes make this 14.00-inch GT ring non-directional despite its slotted friction face. The narrow 0.81-inch section and twelve-bolt mounting flange are intended for a matched caliper-and-hat system rather than an axle-specific universal fit. Wilwood Engineering is based in Camarillo, California and was founded by Bill Wood in 1977. It designs and manufactures disc brake systems for motorsport, street-performance and specialized applications. The range covers calipers, brake rotors, master cylinders, valves, fittings and brake lines, all of which require selection around the full brake system rather than an isolated dimension.
Technical Details
- Manufacturer part number: 160-12884
- Diameter and thickness: 14.00 inches diameter x 0.81 inches wide
- Ring material: Iron
- Face pattern and coating: GT Slotted; Plain
- Internal layout: 36 vanes; straight
- Mounting direction: Non-directional
- Balancing and burnishing: Factory burnished no; balanced yes
- Rotor-to-hat/hub attachment circle: 12 x 8.75 inches
- Attachment hole size or thread: 0.251 inches
- Center / lug registration: 8.25 inches
- Far-side inside diameter: 10.00 inches
- Approximate component weight: 13.40 lb
- Quantity: one rotor ring; hat, hub, mounting hardware, calipers and pads are separate
Fitment & Compatibility
This ring is a component of a matched brake system. Confirm 0.81-inch rotor clearance through the caliper, the 14.00-inch radial envelope and the separate hat's 12 x 8.75-inch attachment. Its 8.25-inch registration must locate concentrically on the specified mounting hardware. Select pads and operating duty to suit the rotor material and the intended brake system.
Manufacturer reference: Wilwood rotor specifications
PMB Performance can help you identify the matching brake components, drawing on over 20 years of experience. Include the current kit number and mounting measurements when requesting a fitment check.
