Product details
The solid 11.44-inch Super Alloy ring is intended for the rear drag brake application specified for this rotor. Drilling reduces rotating material, while the conventional eight-bolt mounting flange distinguishes it from the dynamic lug-mount alternative. Wilwood Engineering, established by Bill Wood in 1977 and based in Camarillo, California, designs and manufactures disc brake systems. Its component range spans brake rotors and calipers alongside master cylinders, valves, fittings and brake lines for motorsport, street-performance and specialized applications. The complete brake system governs which components belong together.
Technical Details
- Manufacturer part number: 160-12155
- Rotor size: 11.44 inches diameter x 0.35 inches wide
- Rotor material: Super Alloy
- Face and finish: Drilled; Plain
- Vanes: Solid, unvented
- Mounting direction: Non-directional
- Factory condition: Factory burnished no; balanced no
- Rotor-to-hat/hub attachment circle: 8 x 7.00 inches
- Attachment hole size or thread: 0.316 inches
- Center / lug registration: 6.38 inches
- Approximate component weight: 5.00 lb
- Quantity: one rotor ring; hat, hub, mounting hardware, calipers and pads are separate
Fitment & Compatibility
For the corresponding rear drag-racing system with an eight-bolt, 7.00-inch mounting circle. The 0.35-inch solid Super Alloy ring is intended for drag-race duty only and is not recommended for street use. Match the retained hat, caliper and pad coverage.
Manufacturer reference: Wilwood rotor specifications
Contact PMB Performance with the rotor and brake-system details for fitment assistance informed by more than 20 years of experience.
