Product details
The hat face is supplied without a wheel-stud pattern for a custom rear installation. This plain 11.00-inch rotor retains the 1.91-inch offset and internal parking drum, requiring properly specified machining before it can match an axle flange. Since its founding by Bill Wood in 1977, Wilwood Engineering has designed and manufactured disc brake systems from Camarillo, California. The product range includes calipers, brake rotors, master cylinders, valves, fittings and brake lines for motorsport, street-performance and specialized installations. Each selection must meet the requirements of the complete brake system.
Technical Details
- Manufacturer part number: 160-11519
- Diameter and thickness: 11.00 inches diameter x 0.81 inches wide
- Ring material: Iron
- Face pattern and coating: Plain Face; Plain
- Internal layout: 32 vanes; straight
- Mounting direction: Non-directional
- Balancing and burnishing: Factory burnished no; balanced no
- Center / lug registration: 3.06 inches
- Far-side inside diameter: 8.38 inches
- Hat offset: 1.910 inches
- Internal parking-drum diameter: 7.24 inches
- Inside clearance diameter: 7.16 inches
- Hat mounting-face thickness: 0.18 inches
- Approximate component weight: 11.80 lb
- Quantity: one rotor with integral hat; separate hub, pads, calipers, mounting hardware and any parking-brake mechanism are not included
Fitment & Compatibility
This blank-pattern 11.00-inch rear rotor requires professional machining of the correct stud-clearance pattern before installation. Confirm the 1.91-inch offset, 3.06-inch registration and internal drum against the low-profile rear brake kit. Optional register adapters are available separately for specified 2.00–2.86-inch axle registers.
Manufacturer reference: Wilwood rotor specifications
PMB Performance can help you identify the matching brake components, drawing on over 20 years of experience. Include the current kit number and mounting measurements when requesting a fitment check.
