Wilwood Front ProMatrix D1463 Pads for Selected Ford Mustang Brake Packages (2005–2014)

The D1463 profile is a front pad in the listed Mustang applications and independent profile references. Wilwood's drawing labels it rear and gives 0.655 inch, while the exact ProMatrix page states 0.66 inch; those conflicting references should not override a physical caliper check. Wilwood Engineering, founded in 1977 by Bill Wood, designs and manufactures disc brake systems and components in its role as a Camarillo, California-based brake specialist. Its range serves motorsport, street-performance and specialized applications through calipers, brake rotors, master cylinders, valves, fittings and brake lines. Selection of each part must match the complete brake system's requirements.

Technical Details

• Manufacturer part number: 150-D1463K
• Pad type: ProMatrix replacement brake pad set
• Pad profile: D1463
• Quantity: 4 pads
• Position: Front
• Nominal thickness (Wilwood specification): .66 inch
• Compatible rotor material: Steel, Iron
• Compound application: Street, autocross and track-day applications
• Friction characteristics: Medium friction; engagement builds with temperature, with a medium wear rate at high temperatures.
• Factory bedded: No
• Published weight: 4.400 lb
• Wilwood dust rating: Low to Moderate
• Wilwood noise rating: Low
• Drawing thickness, inner / outer: .655 / .655 inch

WARNING: This product can expose you to chemicals including Arsenic, Cadmium, Chromium (Hexavalent compounds), Lead, Nickel, Cobalt and Antimony Trioxide which are known to the State of California to cause cancer or other reproductive harm. For more information go to www.p65warnings.ca.gov.

Fitment & Compatibility

Confirm the actual front brake package on the 2005–2014 Mustang. Several rows distinguish Shelby, Bullitt, GT and performance brakes, and some Brembo-labeled entries need confirmation against the caliper's pad outline before purchase.

Application coverage, subject to the brake and equipment qualifications below: Ford Mustang (2005–2014).

Use the fitment table below to confirm the exact year, model, trim and brake configuration. Compare the pad outline and installed caliper where a vehicle has been modified.

Wilwood pad specifications and compatible-caliper reference · Wilwood LeafMark brake-pad technical reference

With over 20 years of experience, PMB Performance can help compare the pad profile with your brake configuration. Include the vehicle year, brake package and clear caliper details when requesting a fitment check.

Vehicle Applications
