Wilwood Front/Rear ProMatrix Pads for Listed Silverado/Sierra 2500 HD and 3500 HD; Rear Pads for Silverado/Sierra 1500 and Express/Savana 3500/4500 Applications (2009–2019)

The D1411 ProMatrix profile is used at more than one axle location across the listed GM applications. Nominally 0.775 inch thick, it serves qualified HD pickup front or rear brakes and specified rear brakes on other pickups and vans; position must be read by vehicle row. Wilwood Engineering's range covers calipers, brake rotors, master cylinders, valves, fittings and brake lines, selected to meet the needs of a complete brake system. The company was founded by Bill Wood in 1977 and is based in Camarillo, California, designing and manufacturing disc brake systems for motorsport, street-performance and specialized applications.

Technical Details

• Manufacturer part number: 150-D1411K
• Pad type: ProMatrix replacement brake pad set
• Pad profile: D1411
• Quantity: 4 pads
• Position: Front/Rear
• Nominal thickness (Wilwood specification): .775 inch
• Compatible rotor material: Steel, Iron
• Compound application: Street, autocross and track-day applications
• Friction characteristics: Medium friction; engagement builds with temperature, with a medium wear rate at high temperatures.
• Factory bedded: No
• Published weight: 7.500 lb
• Wilwood dust rating: Low to Moderate
• Wilwood noise rating: Low

WARNING: This product can expose you to chemicals including Arsenic, Cadmium, Chromium (Hexavalent compounds), Lead, Nickel, Cobalt and Antimony Trioxide which are known to the State of California to cause cancer or other reproductive harm. For more information go to www.p65warnings.ca.gov.

Fitment & Compatibility

Do not apply the drawing's rear caption as a universal axle assignment. Check Silverado/Sierra 2500 HD and 3500 HD rows separately from 1500 pickups and Express/Savana 3500 or 4500 vans, retaining dual-wheel and cutaway exclusions where listed.

Application coverage, subject to the brake and equipment qualifications below: Chevrolet Silverado 2500 HD (2011–2019); Chevrolet Silverado 3500 HD (2015–2019); GMC Sierra 2500 HD (2011–2019); GMC Sierra 3500 HD (2015–2019); Chevrolet Express 3500 (2010–2014); Chevrolet Express 4500 (2009–2014); Chevrolet Silverado 3500 HD Pickup (2011–2014); GMC Savana 3500 (2010–2014); GMC Savana 4500 (2009–2014); GMC Sierra 3500 HD Pickup (2011–2014); Chevrolet Silverado 1500 Pickup (2012–2013); GMC Sierra 1500 Pickup (2012).

Use the fitment table below to confirm the exact year, model, trim and brake configuration. Compare the pad outline and installed caliper where a vehicle has been modified.

Wilwood pad specifications and compatible-caliper reference · Wilwood LeafMark brake-pad technical reference

Use PMB Performance's 20-plus years of experience when the fitted brake package is uncertain. A caliper reference and comparison with the removed pad are useful alongside the vehicle's year and model.

Vehicle Applications
