Wilwood Front ProMatrix D924 Pads for Hyundai Tiburon (2005–2008) and Elantra Sedan (2009–2010)

Hyundai applications for this D924 set distinguish the Tiburon from the later Elantra sedan. ProMatrix friction is supplied at a nominal 0.665-inch thickness, with the illustrated plate defining the replacement front pad. Since its founding by Bill Wood in 1977, Wilwood Engineering has developed a range serving motorsport, street-performance and specialized brake applications. Based in Camarillo, California, it designs and manufactures disc brake systems, calipers, brake rotors, master cylinders, valves, fittings and brake lines. Each component should be selected for compatibility with the complete braking system.

Technical Details

• Manufacturer part number: 150-D0924K
• Pad type: ProMatrix replacement brake pad set
• Pad profile: D924
• Quantity: 4 pads
• Position: Front
• Nominal thickness (Wilwood specification): .665 inch
• Compatible rotor material: Steel, Iron
• Compound application: Street, autocross and track-day applications
• Friction characteristics: Medium friction; engagement builds with temperature, with a medium wear rate at high temperatures.
• Factory bedded: No
• Published weight: 4.000 lb
• Wilwood dust rating: Low to Moderate
• Wilwood noise rating: Low
• Drawing thickness, inner / outer: .665 / .665 inch

WARNING: This product can expose you to chemicals including Arsenic, Cadmium, Chromium (Hexavalent compounds), Lead, Nickel, Cobalt and Antimony Trioxide which are known to the State of California to cause cancer or other reproductive harm. For more information go to www.p65warnings.ca.gov.

Fitment & Compatibility

Observe the Tiburon's 2.0-liter and Base, SE or GS qualifications where listed. The Elantra application is sedan for 2009–2010; other body styles are not established by that entry.

Application coverage, subject to the brake and equipment qualifications below: Hyundai Tiburon (2005–2008); Hyundai Elantra (2009–2010).

Use the fitment table below to confirm the exact year, model, trim and brake configuration. Compare the pad outline and installed caliper where a vehicle has been modified.

Wilwood pad specifications and compatible-caliper reference · Wilwood LeafMark brake-pad technical reference

For help checking this application, contact PMB Performance with the vehicle and installed brake details. Our team draws on over 20 years of experience with parts and brake fitment.
