Wilwood Front ProMatrix Pads for Tacoma (2005–2015), Avalon (2006–2007), Sienna (2004–2010), Solara (2003–2008) and Camry (2005–2006)

The D906A ProMatrix pad is listed for front brake configurations on these Toyota applications. Its nominal 0.685-inch thickness accompanies a drawing whose rear caption conflicts with the front application, so match the plate and caliper instead of relying on that caption. Wilwood Engineering, founded in 1977 by Bill Wood, designs and manufactures disc brake systems and components in its role as a Camarillo, California-based brake specialist. Its range serves motorsport, street-performance and specialized applications through calipers, brake rotors, master cylinders, valves, fittings and brake lines. Selection of each part must match the complete brake system's requirements.

Technical Details

• Manufacturer part number: 150-D0906AK
• Pad type: ProMatrix replacement brake pad set
• Pad profile: D906A
• Quantity: 4 pads
• Position: Front
• Nominal thickness (Wilwood specification): .685 inch
• Compatible rotor material: Steel, Iron
• Compound application: Street, autocross and track-day applications
• Friction characteristics: Medium friction; engagement builds with temperature, with a medium wear rate at high temperatures.
• Factory bedded: No
• Published weight: 3.700 lb
• Wilwood dust rating: Low to Moderate
• Wilwood noise rating: Low

WARNING: This product can expose you to chemicals including Arsenic, Cadmium, Chromium (Hexavalent compounds), Lead, Nickel, Cobalt and Antimony Trioxide which are known to the State of California to cause cancer or other reproductive harm. For more information go to www.p65warnings.ca.gov.

Fitment & Compatibility

Tacoma coverage specifies the base two-wheel-drive five-lug configuration where shown. Engine, assembly origin and rear disc or drum equipment further qualify the passenger-car entries; do not apply the Tacoma range to six-lug front brakes.

Application coverage, subject to the brake and equipment qualifications below: Toyota Tacoma (2005–2015); Toyota Avalon (2006–2007); Toyota Sienna (2004–2010); Toyota Solara (2003–2008); Toyota Camry (2005–2006).

Use the fitment table below to confirm the exact year, model, trim and brake configuration. Compare the pad outline and installed caliper where a vehicle has been modified.

Wilwood pad specifications and compatible-caliper reference · Wilwood LeafMark brake-pad technical reference

PMB Performance brings over 20 years of brake and parts experience to fitment checks. Send your vehicle details and caliper identification if you need help confirming this pad selection.
