Wilwood Rear ProMatrix Pads for Listed Bravada, SSR, TrailBlazer/TrailBlazer EXT, Envoy/Envoy XL/Envoy XUV, Rainier, Saab 9-7x, Ascender, Acadia, Outlook and Enclave Applications (2002–2009)

D883 is the rear pad profile identified by the application entries for this ProMatrix set. The supplied drawing's front caption conflicts with those rear applications, and its 0.685-inch thickness differs slightly from the nominal 0.69-inch product specification. For Wilwood Engineering, component selection forms part of matching a complete brake system to its application. Founded in 1977 by Bill Wood and based in Camarillo, California, the company designs and manufactures disc brake systems and a range of calipers, brake rotors, master cylinders, valves, fittings and brake lines for motorsport, street-performance and specialized applications.

Technical Details

• Manufacturer part number: 150-D0883K
• Pad type: ProMatrix replacement brake pad set
• Pad profile: D883
• Quantity: 4 pads
• Position: Rear
• Nominal thickness (Wilwood specification): .69 inch
• Compatible rotor material: Steel, Iron
• Compound application: Street, autocross and track-day applications
• Friction characteristics: Medium friction; engagement builds with temperature, with a medium wear rate at high temperatures.
• Factory bedded: No
• Published weight: 3.800 lb
• Wilwood dust rating: Low to Moderate
• Wilwood noise rating: Low
• Thickness marked on drawing: .685 inch — differs from the nominal product specification; confirm before ordering

WARNING: This product can expose you to chemicals including Arsenic, Cadmium, Chromium (Hexavalent compounds), Lead, Nickel, Cobalt and Antimony Trioxide which are known to the State of California to cause cancer or other reproductive harm. For more information go to www.p65warnings.ca.gov.

Fitment & Compatibility

Match the rear caliper on the exact model-year row, including the separate Acadia, Outlook and Enclave entries. Bravada, SSR, TrailBlazer variants, Envoy variants, Rainier, 9-7x and Ascender each have their own limits; use the outline rather than the erroneous axle caption.

Application coverage, subject to the brake and equipment qualifications below: Oldsmobile Bravada (2002–2004); Chevrolet SSR (2004–2006); Chevrolet TrailBlazer (2002–2009); Chevrolet TrailBlazer EXT (2002–2006); GMC Envoy (2002–2009); GMC Envoy XL (2003–2006); Buick Rainier (2004–2007); Saab 9-7x (2005–2009); Isuzu Ascender (2003–2008); GMC Acadia (2007–2008); GMC Envoy XUV (2004–2005); Saturn Outlook (2007–2008); Buick Enclave (2008).

Chevrolet’s extended-wheelbase model is the TrailBlazer EXT, listed as “Trailblazer XT” in the table. Its listed 2002–2006 rear applications require the D883 pad profile.

Use the fitment table below to confirm the exact year, model, trim and brake configuration. Compare the pad outline and installed caliper where a vehicle has been modified.

Wilwood pad specifications and compatible-caliper reference · Wilwood LeafMark brake-pad technical reference · Manufacturer pad-profile application catalog

With over 20 years of experience, PMB Performance can help compare the pad profile with your brake configuration. Include the vehicle year, brake package and clear caliper details when requesting a fitment check.

Vehicle Applications
