Wilwood Front ProMatrix Pads for Listed Bravada, SSR, TrailBlazer/TrailBlazer EXT, Envoy/Envoy XL/Envoy XUV, Rainier, Ascender and Saab 9-7x Applications (2002–2005)

The D882 front plate serves the listed midsize SUV and SSR brake applications. Wilwood gives a nominal 0.66-inch thickness for the ProMatrix set, with 0.655 inch shown on its drawing, so retain that distinction when comparing the removed pad. Bill Wood established Wilwood Engineering in 1977, and the company is based in Camarillo, California. It designs and manufactures disc brake systems, including calipers, brake rotors, master cylinders, valves, fittings and brake lines, for motorsport, street-performance and specialized use. The individual parts must be selected as compatible elements of the complete brake system.

Technical Details

• Manufacturer part number: 150-D0882K
• Pad type: ProMatrix replacement brake pad set
• Pad profile: D882
• Quantity: 4 pads
• Position: Front
• Nominal thickness (Wilwood specification): .66 inch
• Compatible rotor material: Steel, Iron
• Compound application: Street, autocross and track-day applications
• Friction characteristics: Medium friction; engagement builds with temperature, with a medium wear rate at high temperatures.
• Factory bedded: No
• Published weight: 5.100 lb
• Wilwood dust rating: Low to Moderate
• Wilwood noise rating: Low
• Thickness marked on drawing: .655 inch — differs from the nominal product specification; confirm before ordering

WARNING: This product can expose you to chemicals including Arsenic, Cadmium, Chromium (Hexavalent compounds), Lead, Nickel, Cobalt and Antimony Trioxide which are known to the State of California to cause cancer or other reproductive harm. For more information go to www.p65warnings.ca.gov.

Fitment & Compatibility

Bravada, SSR, TrailBlazer, the listed TrailBlazer EXT, Envoy, Envoy XL, Envoy XUV, Rainier, Ascender and 9-7x have individual year limits. The family relationship is not permission to extend coverage outside those entries.

Application coverage, subject to the brake and equipment qualifications below: Oldsmobile Bravada (2002–2004); Chevrolet SSR (2004–2005); Chevrolet TrailBlazer (2002–2005); Chevrolet TrailBlazer EXT (2002–2005); GMC Envoy (2002–2005); GMC Envoy XL (2003–2005); Buick Rainier (2004–2005); Isuzu Ascender (2003–2005); GMC Envoy XUV (2004–2005); Saab 9-7x (2005).

The application table calls the extended-wheelbase TrailBlazer EXT “Trailblazer XT”. For this model, match the D882 front-pad profile within the listed 2002–2005 years.

Use the fitment table below to confirm the exact year, model, trim and brake configuration. Compare the pad outline and installed caliper where a vehicle has been modified.

Wilwood pad specifications and compatible-caliper reference · Wilwood LeafMark brake-pad technical reference · Manufacturer pad-profile application catalog

PMB Performance brings over 20 years of brake and parts experience to fitment checks. Send your vehicle details and caliper identification if you need help confirming this pad selection.
