Product details
Three retention holes identify this 6812 BP10 pad for the listed Dynalite Single and Dynapro Single calipers. Wilwood's product page and drawing publish slightly different thicknesses, so the supplied dimension must be confirmed against the caliper before ordering. Since its founding by Bill Wood in 1977, Wilwood Engineering has developed a range serving motorsport, street-performance and specialized brake applications. Based in Camarillo, California, it designs and manufactures disc brake systems, calipers, brake rotors, master cylinders, valves, fittings and brake lines. Each component should be selected for compatibility with the complete braking system.
Technical Details
- Manufacturer part number: 150-9764K
- Pad type: BP10 replacement brake pad set
- Pad profile: 6812
- Quantity: 4 pads
- Position: Installation-dependent; confirm the actual caliper application
- Nominal thickness (Wilwood specification): .49 inch
- Compatible rotor material: Steel, Iron
- Compound application: Street use, muscle cars, drag racing and light to medium dirt-track braking
- Friction characteristics: Medium friction with a gradual response, low wear on iron rotors and low to medium wear at low operating temperatures.
- Caliper selection: Listed Dynalite Single and Dynapro Single calipers using the 6812 plate
- Pad area: 3 sq in
- Pad volume: 1.1 cu in
- Factory bedded: No
- Published weight: 1.100 lb
- Wilwood dust rating: Low
- Wilwood noise rating: Low
- Thickness marked on drawing: .50 inch — differs from the nominal product specification; confirm before ordering
WARNING: This product can expose you to chemicals including Arsenic, Cadmium, Chromium (Hexavalent compounds), Lead, Nickel, Cobalt and Antimony Trioxide which are known to the State of California to cause cancer or other reproductive harm. For more information go to www.p65warnings.ca.gov.
Fitment & Compatibility
The narrow 1.98-inch plate is used by several DLS and DPS versions, including the specified floating and lightweight models. Check the full caliper designation and all three retention points; the physical profile must be established before choosing between BP10 and the other available compounds.
Wilwood pad specifications and compatible-caliper reference · Wilwood LeafMark brake-pad technical reference
PMB Performance brings over 20 years of brake and parts experience to fitment checks. Send your vehicle details and caliper identification if you need help confirming this pad selection.
