Product details
The three-hole backing plate identifies this BP20 set for the listed Dynalite Single and Dynapro Single calipers. Its compact 0.49-inch profile must match the specific single-caliper model, including the retaining arrangement shown in the pad drawing. The brake-system manufacturer Wilwood Engineering was founded by Bill Wood in 1977 and is based in Camarillo, California. It designs and manufactures disc brake systems, covering motorsport, street-performance and specialized needs with calipers, brake rotors, master cylinders, valves, fittings and brake lines. Component compatibility must be assessed across the whole installation.
Technical Details
- Manufacturer part number: 150-20-6812K
- Published pad area: 3 square inches
- Published pad volume: 1.1 cubic inches
- Rotor compatibility: Steel, Stainless Steel, Iron
- Bedding status: not pre-bedded; follow Wilwood bedding procedure
- Pad profile: 6812
- Friction compound: BP20
- Package quantity: 4 pads
- Pad thickness: .49 inch
Fitment & Compatibility
Wilwood’s compatible-caliper list names Billet Dynalite Single, Dynalite Single 4, Dynalite Single Floater, Dynalite Single IIIA, Dynapro Single, Dynapro Single LW, Dynapro Single Polished, Dynapro Single VW. Verify the required new-pad thickness alongside the plate’s contact and mounting surfaces. Rotor material and operating temperature must also match the friction compound; a shape match alone is insufficient.
BP20 is a medium-friction compound with a broader effective temperature range than BP10. Wilwood lists street driving, autocross, track days, drag racing and medium-braking dirt or pavement competition on iron, steel or stainless-steel rotors. Friction rises with temperature; dust and noise are rated low to moderate.
Reference: Wilwood product specifications and compound guidance. Manufacturer profile illustration.
PMB Performance brings more than 20 years of brake-system experience to component selection. Send the caliper identification and pad measurements if you need help matching the replacement.
