Wilwood SC10 Metallic Replacement Brake Pad Set

These metallic replacement pads use the SC10 two-piston caliper profile. Wilwood publishes different thickness measurements and compound labels, so confirm the supplied pad dimensions and friction material before selecting this set. Disc brake system design and manufacturing are Wilwood Engineering’s focus. The company was founded by Bill Wood in 1977 and is based in Camarillo, California; its motorsport, street-performance and specialized product range includes calipers, brake rotors, master cylinders, valves, fittings and brake lines. The mating components matter as much as the individual part.

Technical Details

• Manufacturer part number: 150-15799K
• Pad profile: 10008
• Published friction labels: CM on the product page; SM in Wilwood’s parts-search description. Confirm the supplied friction material and intended brake duty with Wilwood.
• Package quantity: 4 pads
• Published pad thickness: 0.185 inch on the product page; 0.31 inch on the profile drawing. Confirm the supplied dimension with Wilwood.
• Product-page rotor-material list: steel, stainless steel, iron, super alloy and titanium. Confirm compatibility for the actual supplied compound and intended mechanism.
• Bedding status: not pre-bedded; follow Wilwood bedding procedure

Fitment & Compatibility

Wilwood’s compatible-caliper list names SC10 2 Piston. Confirm the supplied pad thickness and required clearance with Wilwood before ordering. The product page gives 0.185 inch and the profile drawing gives 0.31 inch; a matching outline does not make these dimensions interchangeable.

Wilwood’s product page identifies CM and its parts-search description identifies SM. Obtain confirmation of the actual material and approved use in the SC10 assembly. The general CM performance chart does not settle the supplied formulation or establish rotor compatibility for this disputed listing.

Reference: Wilwood product specifications and compound guidance. Manufacturer profile illustration.

With over 20 years of experience, PMB Performance can help compare the installed brake package with the required pad profile and compound. Caliper details are more useful than a vehicle model alone on a modified system.
