Wilwood Rear D667 Street Brake Pad Set with BP10 Material

The D667 backing plate defines the fit of this four-pad BP10 replacement set. Its nominal 0.58-inch listing rounds the profile drawing's 0.575-inch dimension, so use the caliper specification when checking the required new-pad clearance. Disc brake system design and manufacturing are Wilwood Engineering’s focus. The company was founded by Bill Wood in 1977 and is based in Camarillo, California; its motorsport, street-performance and specialized product range includes calipers, brake rotors, master cylinders, valves, fittings and brake lines. The mating components matter as much as the individual part.

Technical Details

• Manufacturer part number: 150-10-D0667K
• Package quantity: 4 pads
• Pad thickness: .58 inch (nominal)
• Rotor compatibility: Steel, Iron
• Pad profile: D667
• Friction compound: BP10

This set uses BP10, Wilwood’s street-oriented friction material for steel and iron rotors. It combines gradual response with low noise and dust ratings, and is also listed for drag racing and lighter dirt-track use. Match those characteristics to the vehicle’s duty instead of treating all racing compounds as interchangeable.

Fitment & Compatibility

The manufacturer’s pad-profile drawing identifies rear use for this plate. Match the actual caliper and its new-pad specification; the drawing caption does not establish blanket model or year coverage. Check the pad’s mounting outline against the installed caliper before choosing this set. A shared friction compound does not make different plate profiles interchangeable, and axle position cannot be inferred from the compound.

Reference: Wilwood pad-profile drawing. Wilwood BP10 compound characteristics.

PMB Performance has worked with brake components for more than 20 years. Contact us with the installed caliper and rotor details when the correct replacement is unclear.
