Wilwood BP10 D3 Brake Pad Set, 0.59-Inch Thickness

The D3 plate makes this BP10 set a replacement for calipers accepting that specific pad outline. Four pads with a listed 0.59-inch new-pad thickness provide street-oriented friction for an iron or steel rotor installation. Since Bill Wood established Wilwood Engineering in 1977, its work has centered on the design and manufacture of disc brake systems. The Camarillo, California company supplies calipers and brake rotors alongside master cylinders, valves, fittings and brake lines for motorsport, street-performance and specialized uses, with each component matched to the complete system.

Technical Details

• Manufacturer part number: 150-10-D0003K
• Friction compound: BP10
• Package quantity: 4 pads
• Pad thickness: .59 inch
• Rotor compatibility: Steel, Iron
• Pad profile: D3

The BP10 friction material emphasizes smooth initial response and moderate-temperature operation. Appropriate uses include street driving, drag racing and lighter dirt-track braking on iron or steel rotors. Choose a different compound when sustained braking heat exceeds this operating role.

Fitment & Compatibility

Before ordering, compare the removed pad with the profile drawing and check the caliper’s allowed thickness. Confirm both retention geometry and rotor material rather than relying on a similar overall pad outline.

Reference: Wilwood BP10 compound characteristics.

With over 20 years of experience, PMB Performance can help compare the installed brake package with the required pad profile and compound. Caliper details are more useful than a vehicle model alone on a modified system.
