Wilwood Rear 12.19-Inch SRP Brake Set with Red Calipers for Chevrolet 12-Bolt C-Clip-Eliminator Ends

Red Dynalite calipers pair with Wilwood drilled/slotted rear rotors on Chevy 12-bolt eliminator axles. Resolve the offset and check wheel clearance. Wilwood Engineering, founded by Bill Wood in 1977, is based in Camarillo, California. It designs and manufactures disc brake systems for motorsport, street-performance and specialized applications. Its calipers, brake rotors, master cylinders, valves, fittings and lines must be selected to suit the complete braking system.

Technical Details

• Manufacturer part number: 140-5236-DR
• Rotor material and size: Choose this 12.19 x 0.81-inch srp drilled and slotted rotor configuration. The rotor material is iron and its construction is vented.
• Caliper specification: Finish selection is red powder coat. Each forged aluminum caliper carries 4 pistons with stainless construction.
• Caliper interface: 1/8-27 NPT inlet thread; calipers attach through the specified lug mounting layout.
• Housing-end requirement: 12 Bolt C-Clip Eliminator; Offset requires confirmation: manufacturer product page and instruction cover disagree.
• Rotor/hat wheel-stud clearance pattern: 5 X 4.5 in; 5 X 4.75 in; 5 X 5 in (5 X 114.3 mm; 5 X 120.65 mm; 5 X 127 mm)
• Wheel fit: Check the wheel-clearance diagram; the listed minimum wheel diameter is 15 inches.
• Kit supply: mounting hardware
• Not included: master cylinder, booster, spindles, flexible brake lines, hubs
• Parking brake: No parking-brake mechanism supplied

Fitment & Compatibility

This red-caliper SRP configuration requires the Chevrolet 12-bolt C-clip-eliminator mounting arrangement. Measure the actual axle and identify the eliminator before selection. DS-267 states 2.81-inch offset, while the product page states 2.91 inches; obtain Wilwood confirmation of the complete assembly. The table below provides conditional vehicle context, so its front-spindle descriptions do not identify the rear housing end.
