Wilwood Front Dynapro Single Drag Brakes for Chassis Engineering Struts, Two-Piston Calipers/10-Inch Rotors

Chassis Engineering strut drag kit with fixed two-piston Wilwood calipers and 10-inch drilled rotors. Confirm mounting and under-2,400-pound use. Founded in 1977 under Bill Wood, Wilwood Engineering operates from Camarillo, California. The company designs and manufactures disc brake systems and the calipers, rotors, master cylinders, valves, fittings and lines used within them. Its motorsport, street-performance and specialized applications depend on compatible brake components.

Technical Details

• Manufacturer part number: 140-4399-BD
• Brake calipers: For this package, the billet aluminum calipers have type iii anodized exteriors and stainless pistons, 2 per caliper.
• Rotor geometry: Each rotor is 0.32 inch wide with a 10.00-inch outside diameter; the solid steel design has drilled surfaces.
• Installation interfaces: Confirm lug mounting and a hydraulic connection compatible with the 1/8-27 NPT inlet.
• Hub wheel drilling: 5 x 4.5 in; 5 x 4.75 in (5 x 114.3 mm; 5 x 120.65 mm)
• Wheel fit: Wheel diameter alone is insufficient: test the template for this nominal 14-inch minimum package.
• Package scope: Supplied: hubs, mounting hardware. Not included: master cylinder, booster, spindles, flexible brake lines.
• Intended vehicle: Four-wheel-disc drag car under 2,400 lb; verify Chassis Engineering strut arrangement
• Caliper design: Dynapro Single fixed two-piston caliper; not a single-piston floater

Fitment & Compatibility

Wilwood specifies this Dynapro Single family for four-wheel-disc drag cars weighing under 2,400 pounds. Confirm the Chassis Engineering strut and mounting bracket with Wilwood; no installation sheet is linked for this exact kit. Verify wheel clearance and the complete brake system rather than relying on the generic factory-disc-spindle field.

Wilwood kit specifications and component list
