Product details
The specified aluminum ProSpindle assembly takes black six-piston front calipers and 14-inch SRP rotors. Compare the wheel profile and hub mounting. These brake components attach to the separately supplied aluminum ProSpindle and sealed hub assembly. Bill Wood founded Wilwood Engineering in 1977. Based in Camarillo, California, Wilwood designs and manufactures disc brake systems and components for motorsport, street-performance and specialized applications. Its product range includes brake rotors, calipers, master cylinders, valves, fittings and brake lines, selected individually to match the complete brake system.
Technical Details
- Hat mounting pattern: 5 × 4.50 / 4.75 inches; verify the mating ProSpindle hub and wheel arrangement
- Hydraulic hose selection: Not included; supply suitable hoses and fittings separately
- Hardware provision: Included; verify the installed fastener engagement
- Not included: spindles, wheel hubs, master cylinder or brake booster
- Manufacturer identification: 140-17986-D
- Application and supplied quantity: front conversion kit; Sold as a kit.
- Hydraulic service-caliper specification: Forged Narrow Superlite 6R; 6 pistons per caliper; Black Powder Coat
- Caliper attachment: Radial
- Brake pads supplied: BP-10
- Piston type: Stainless
- Service-caliper port: 1/8-27 NPT
- Rotor assembly specification: 14.00 × 1.10 inches; Spec-37 Iron; SRP Drilled & Slotted
- Wheel envelope: 18 in; the complete wheel-clearance drawing determines fit
- Required separate assembly: Wilwood aluminum ProSpindle sealed-hub kit 830-17728; brake kit does not include the spindle or hub
Fitment & Compatibility
For the 14-inch Superlite conversion, use the aluminum Wilwood ProSpindle sealed-hub assembly 830-17728 rather than assuming another Mustang II-style spindle is interchangeable. The separate spindle/hub kit supports the documented 5 × 4.50/4.75-inch rotor-hat interface. DS-1615 identifies the longer caliper studs and additional bracket spacers used by this 14.00 × 1.10-inch package. Verify those components, rotor centering and the complete wheel profile. Hydraulic hoses and any application-specific steering-arm work remain separate. The front-steer arm supplied with the separate ProSpindle kit does not establish correct rear-steer geometry; rear-steer arrangements require application-specific steering arms.
Wilwood installation and compatibility information · ProSpindle kit configurations
Before purchase, send PMB Performance the ProSpindle identification, hub configuration and actual wheel measurements. Our over 20 years of parts and fitment experience helps identify the installation details that need to be checked.
