Wilwood DPC56 Four-Piston Rear Race Conversion with 12-Inch Rotors for Corvette C5 and Base C6 (1997–2013), Parking Brake Removed

DPC56 four-piston rear calipers and two-piece rotors fit listed Corvette C5 and base C6 models. Check Z06 wheel clearance; parking brake is deleted. Bill Wood founded Wilwood Engineering in 1977 in Camarillo, California, where the company is based. Wilwood designs and manufactures disc brake systems, producing brake rotors, calipers, master cylinders, fittings, valves and brake lines for motorsport, street-performance and specialized applications. Individual parts are selected to meet the requirements of the complete braking system.

Technical Details

• Manufacturer part number: 140-16531
• Kit function: Rear Brake Kits - Road Race; rear position
• Service calipers: 4-piston DPC56; Type III Anodize
• Rotor package: 12.00 × 1.03 inches; Iron; vented; Plain Face
• Supplied service-pad compound: BP-40
• Rotor / hub bolt-circle specification: 5 x 4.75 in; 5 x 120.65 mm
• Nominal wheel diameter reference: 17 in; verify the complete clearance drawing
• Hydraulic flexlines: Not included; listed optional reference 220-8072, 220-15194 must be checked for the actual application
• Included installation items: mounting hardware
• Not supplied: spindles, wheel hubs, master cylinder, brake booster
• Quantity: Sold as a kit.

Fitment & Compatibility

Use the fixed four-piston DPC56 rear calipers with the specified 12-inch rotor arrangement on all listed C5 and base C6 Corvette models. The installation removes the parking brake, and DS-1454 calls for Z06 wheel clearance or a verified equivalent wheel profile. The calipers have a Type III anodized finish. BP-40 pads require racing temperatures; prolonged cold operation increases wear. The calipers accept the OE banjo-style hose with new crush washers. Check the complete brake system and listed year/trim coverage.

Use the fitment table below to check each listed year, model and brake configuration alongside these installation requirements.

Wilwood product specifications · Installation instructions

For a race-brake fitment check backed by more than 20 years of parts experience, send PMB Performance the hub, spindle, wheel and complete brake-system details. Selection depends on the actual competition installation.
