Wilwood 14-Inch GT Rear Brake Kit with Red Superlite Calipers and Flexlines for Jeep Gladiator JT (2020–2021)

Retain the Jeep Gladiator JT parking brake with red four-piston rear calipers, slotted 14-inch rotors and flexlines. Verify the wheel profile. Bill Wood founded Wilwood Engineering in 1977 in Camarillo, California, where the company is based. Wilwood designs and manufactures disc brake systems, producing brake rotors, calipers, master cylinders, fittings, valves and brake lines for motorsport, street-performance and specialized applications. Individual parts are selected to meet the requirements of the complete braking system.

Technical Details

• Application / axle position: Rear Brake Kits - Street Performance; rear position
• Rotor specification: 14.00 × 0.81 inches; Iron; vented; GT Slotted
• Supplied service-pad compound: BP-20
• Wheel-size starting point: 18 in; verify the complete clearance drawing
• Flexline inclusion: Included; 220-16180 (20.00 in)
• Caliper family, piston count and finish: 4-piston Forged Narrow Superlite 4R; Red Powder Coat
• Hydraulic inlet: 1/8-27 NPT
• Rotor / hub bolt-circle specification: 5 x 5 in; 5 x 127 mm
• Caliper mounting: Radial; piston material: stainless steel
• Items outside the kit: spindles, wheel hubs, master cylinder, brake booster
• Supplied mounting components: mounting hardware
• Manufacturer part number: 140-16179-R
• Quantity: Sold as a kit.

Fitment & Compatibility

The listed 2020–2021 Jeep Gladiator JT applications retain the original internal parking brake arrangement. Check the Overland, Rubicon, Sport and listed 2021 trim rows individually rather than applying an open-ended year claim. DS-1393 requires the rear dust shield to be cut for rotor clearance; have that work performed by a competent installer. The included 20-inch braided flexlines must clear moving suspension and wheel parts throughout travel. The original hub is reused. Check the actual wheel shape with the manufacturer diagram; an 18-inch nominal diameter alone is insufficient.

Use the fitment table below to check each listed year, model and brake configuration alongside these installation requirements.

Wilwood product specifications · Installation instructions

PMB Performance has more than 20 years of parts and fitment experience. Provide the model, year, installed spindle or hub, existing brake package and wheel measurements so we can help check the complete conversion.
