Wilwood Red Superlite Front Disc Conversion with SRP 12.88-Inch Rotors, Hubs and Lines for 1982–1992 Camaro/Firebird

Red Superlite 6R service calipers clamp SRP rotor rings in this F-body front assembly. Hats, separate aluminum hubs, BP-10 pads and the braided front hose set are included, with preparation of the retained spindle addressed by the installation guide. Bill Wood founded Wilwood Engineering in 1977. Based in Camarillo, California, the company designs and manufactures disc braking systems and components for street-performance, motorsport and specialized use. Its calipers, rotors, master cylinders, valves, fittings and brake lines are chosen around the hydraulic, mounting and balance needs of a complete system.

Technical Details

• Manufacturer part number — 140-15278-DR.
• Hydraulic package contents — brake lines included: Yes; master cylinder included: No; booster included: No.
• Brake function and supply — Front Brake Kits - Street Performance; Disc braking; front axle; Sold as a kit.
• Rotor construction and friction surface — Spec-37 Iron; Vented; SRP Drilled & Slotted; surface finish: Black Electro Coat.
• Caliper color, finish and hydraulic inlet — Red; Red Powder Coat; inlet 1/8-27 NPT.
• Wheel bolt circle — 5 x 4.75 in; 5 x 120.65 mm.
• Nominal minimum wheel diameter — 17 in; 431.8 mm; verify full spoke and barrel clearance using the kit drawing.
• Stated OE wheel-hub offset — +.25 in; verify the documented spindle and reference geometry.
• Flexline specification — Line kit included (manufacturer): 220-6856 (18.00 in); Front line-kit reference: 220-6856.
• Rotor dimensions — outside diameter 12.88 in; 327.15 mm; thickness 1.10 in; 27.94 mm.
• Service caliper assembly — Superlite 6R; 6 pistons in each caliper; Stainless pistons; Forged Aluminium body; Radial mounting.
• Supplied pad compound — BP-10.
• Wheel-stud thread — 1/2-20.
• Rotor mounting hat — aluminum; Black E-Coat; hat offset 1.750 in.
• Mechanical package contents — separate hubs included; mounting hardware included: Yes; spindles included: No.

Fitment & Compatibility

Compare the actual factory spindle with DS1141 before disassembly. Standard spindle/steering-arm parts need drilling, tapping and clearance-ear removal; the 1LE option is explicitly exempt. Confirm 5 x 4.75 wheels, the stated outward hub offset and complete nominal 17-inch brake clearance.

Listed model families are Camaro, Firebird; the individual year and brake/spindle conditions remain decisive. Use the fitment table below to confirm year, model, trim and brake or suspension options.

PMB Performance brings over 20 years of parts and fitment experience. Send the vehicle details and installed brake/suspension configuration if you need help checking this package.

Check the Installation instructions for the full assembly and wheel-clearance requirements.
