Wilwood TCI IFS front parts layout with red Superlite 6R calipers, 12.88-inch slotted rotor rings, separate hubs, bearings, pads and mounting brackets
Wilwood TCI IFS front single-side assembly showing a red Superlite 6R caliper beside a 12.88-inch slotted rotor ring and protruding wheel studs
Wilwood TCI IFS front parts layout with red Superlite 6R calipers, 12.88-inch slotted rotor rings, separate hubs, bearings, pads and mounting brackets
Wilwood TCI IFS front single-side assembly showing a red Superlite 6R caliper beside a 12.88-inch slotted rotor ring and protruding wheel studs

Wilwood Front 12.88-Inch GT Brake Package, Red Superlite 6R Calipers and TCI IFS Hubs

SKU: 140-13224-R

$2,354.40 Sale
Shipping calculated at checkout.

Fitment questions?

Call (855) 786-7101 or text (801) 304-3141.
Real people. Real answers.

Shipping policyRefund policy

Product details

This red front kit supplies slotted 12.88-inch Spec-37 rotors, radial-mount Superlite calipers and replacement hubs. Compatibility is defined by the TCI IFS spindle and its bearing hardware. Bill Wood’s 1977 founding of Wilwood Engineering began a disc brake design and manufacturing business based in Camarillo, California. The range includes master cylinders, calipers, rotors, brake lines, valves and fittings for motorsport, street-performance and specialized vehicles. Component selection must consider the complete braking arrangement.

Technical Details

  • Manufacturer part number: 140-13224-R
  • Application and package: Front Brake Kits - Street Performance; Front Kits; Disc; Sold as a kit.
  • Hydraulic inlet: 1/8-27 NPT
  • Wheel bolt pattern(s): 5 x 4.5 in; 5 x 114.3 mm; 5 x 4.75 in; 5 x 120.65 mm
  • Wheel-stud thread: 1/2-20 in
  • Wheel diameter starting requirement: 17 in; 431.8 mm; verify the individual wheel against the installation drawing
  • Included mechanical components: Mounting hardware: Yes; hub(s): Yes; spindle(s): No
  • Hydraulic components supplied: Master cylinder: No; brake booster: No; brake lines: No
  • Specified pad compound: BP-10
  • Separate rotor-hat specification: Aluminum; Black E-Coat; offset 1.620 inch; part 170-10489
  • Published wheel-position / hub offset: +.34 inch per side; verify against the documented spindle assembly
  • Rotor dimensions: 12.88 in; 327.15 mm outside diameter; 1.10 in; 27.94 mm thickness
  • Rotor construction: Spec-37 Iron; Vented; GT Slotted
  • Caliper assembly: Forged Narrow Superlite 6R; 6 pistons per caliper; Forged Aluminium body; Radial mount
  • Piston and finish specification: Stainless pistons; Red calipers; Red Powder Coat

Fitment & Compatibility

Check the installed TCI nut, lock and bearing spacer against DS1005. A nominal 17-inch wheel must still clear the six-piston body and sit correctly on the hub's mounting face.

Flexible brake lines are not included. Original lines are not assumed to connect to the Wilwood calipers; select the application-specific or correctly sized universal hose and matching fittings.
