Product details
Red D154 calipers clamp SRP drilled/slotted rings in this Wilwood Mopar/Dana rear conversion. The vented rotors are 12.19 inches in diameter, and internal parking shoes work independently of the hydraulic calipers. The hardware is dedicated to a 2.36-inch-offset housing with snap-ring axle bearings. Wilwood Engineering was founded by Bill Wood in 1977 and is based in Camarillo, California. The company designs and manufactures disc brake systems and components, including calipers, brake rotors, master cylinders, valves, fittings, and brake lines. Its product range serves motorsport, street-performance, and specialized applications, with individual components selected to match the requirements of the complete brake system.
Technical Details
- Manufacturer part number: 140-12214-DR
- Type: D154 Rear Parking Brake Kit
- Calipers: D154; 2 pistons per caliper; Red Powder Coat; floating mounting.
- Piston bores: 1.12, 1.12 inches; Stainless pistons. Included pad compound: BP-10.
- Rotors: 12.19-inch diameter × 0.81-inch width; SRP Drilled & Slotted; Iron; Black Electro Coat finish.
- Rear housing end: Mopar/Dana. Axle-flange offset: 2.36 inches.
- Included: paired hydraulic calipers, pads, rotor/hat assemblies, internal parking-shoe assemblies and mounting components.
- Hydraulic flex lines are separate. Master cylinder, booster and spindles are not included; retain or select suitable matching components.
- Conditional minimum wheel diameter: 16 inches. Verify the complete clearance drawing for barrel and spoke offset before purchase.
Fitment & Compatibility
Check the axle-end drawing in DS859 and measure the actual bearing, flange and offset. Confirm that the rotor hat clears the axle flange and fits the wheel studs, with any machining completed as directed before assembly. Inspect shock clearance and select the separate parking-cable and hydraulic connections. Wilwood lists a conditional 16-inch wheel minimum, while some 15-inch wheels are possible only after the full caliper profile has been tested against the wheel section.
Wilwood installation documents: Installation instructions; Technical bulletin.
PMB Performance has over 20 years of brake-system experience. Contact us with your vehicle, axle or spindle details and wheel measurements for fitment help.
