Wilwood Front Drilled/Slotted Rotor Package with Red Six-Piston Calipers, Toyota Matrix S/XRS FWD 2.4L (2009–2011)

Red six-piston Superlite calipers clamp drilled/slotted 12.88-inch rotors in this Wilwood Toyota front kit. Separate hats use the original FWD 2.4L Matrix S/XRS hub arrangement. The 1.10-inch-wide Spec-37 friction rings and caliper brackets must be matched to the exact spindle and wheel envelope. Wilwood Engineering was founded by Bill Wood in 1977 and is based in Camarillo, California. The company designs and manufactures disc brake systems and components, including calipers, brake rotors, master cylinders, valves, fittings, and brake lines for motorsport, street-performance, and specialized applications.

Technical Details

• Manufacturer part number: 140-10752-DR
• Type: Forged Narrow Superlite 6R Big Brake Front Brake Kit (Hat)
• Calipers: Forged Narrow Superlite 6R; 6 pistons; Red Powder Coat.
• Bores: 1.62, 1.12, 1.12 inches. Pads: BP-10.
• Rotors: 12.88-inch diameter × 1.10-inch width; SRP Drilled & Slotted, Spec-37 Iron, Black Electro Coat. 48 curved vanes.
• Wheel bolt circles: 5 x 4.50 inches.
• Included: paired calipers, pads, rotors, brackets and assembly hardware, rotor hats.
• Not included: hydraulic lines, master cylinder, booster or spindles. Reuse suitable matching components.
• Conditional wheel minimum: 17 inches. Check the clearance drawing for barrel and spoke offset.

Fitment & Compatibility

Confirm the 2009–2011 application and 5 × 4.50-inch hub bolt circle in DS647 rather than selecting solely by Matrix body style. Other engine or drivetrain configurations use different equipment. Hydraulic hoses are separate, and the existing hub must be serviceable. Check wheel clearance in radius and spoke depth, then verify rotor alignment and pedal travel before testing.

Match the individual model, year, submodel and brake configuration in the fitment table below.

PMB Performance has over 20 years of brake-system experience. Contact us with the vehicle and installed hardware details for fitment help.
