Product details
The black right-rear CPB combines a hydraulic service brake and cable-operated parking lock in one floating caliper. A 34 mm stainless piston acts within the dust-booted body. This is the standard nominal 0.81-inch rotor-width version, with a fixed radial bracket establishing its position over the rotor. Founded in 1977 by Bill Wood, Wilwood Engineering is based in Camarillo, California. Its disc brake systems and components serve motorsport, street-performance and specialized applications. Calipers, brake rotors, master cylinders, valves, fittings and brake lines are among its products, selected according to the complete brake system’s requirements.
Technical Details
- Manufacturer part number: 120-9808-BK
- Caliper type: Combination Parking Brake
- Construction: Aluminium / Steel
- Finish: Black Powder Coat
- Piston bores: 1.34 inches
- Piston type: Steel
- Piston count: 1
- Published piston area: 1.41 square inches
- Dust boots: Yes
- Nominal rotor width: 0.81 inch
- Rotor thickness limits: 0.75–0.81 inches
- Rotor diameter limits: 11.00–13.00 inches
- Mounting style: Radial
- Mounting side: Right Hand
- Mounting centers: 5.98 inches
- Mounting-hole size: 0.39 inch
- Mount height: 2.08 inch
- Hydraulic inlet thread: M10 x 1.00
- Required pad shape: D340
- Published pad area: 4 square inches
- Published pad volume: 1.5 cubic inches
- Manufacturer-listed component weight: 6.1 lb
Fitment & Compatibility
Verify the rear axle bracket, rotor offset and pad track with the full installation drawing. The selected caliper lists 0.75–0.81-inch rotor thickness and 11.00–13.00-inch diameter limits. Confirm the right-hand cable route, housing stop and end attachment, then check the M10 x 1.00 hydraulic fitting and front-to-rear brake balance.
PMB Performance brings over 20 years of brake and parts experience to selection questions. Send the existing caliper reference and brake-package details for help checking compatibility.
