Product details
The thin-rotor DynaPro shown here uses four 1.38-inch stainless pistons and a black forged aluminum body. A nominal 0.38-inch rotor opening suits the dedicated narrow-rotor configuration. It has a 5.25-inch lug interface and the published 3.00-square-inch piston area, which must agree with the hydraulic design. Based in Camarillo, California, Wilwood Engineering was founded by Bill Wood in 1977. The manufacturer produces disc brake systems and components for motorsport, street-performance and specialized applications, with a range covering calipers, brake rotors, master cylinders, valves, fittings and brake lines. Individual components are chosen to suit the complete brake system.
Technical Details
- Manufacturer part number: 120-9705
- Caliper type: Dynapro Lug Mount
- Construction: Forged Aluminium
- Finish: Black Powder Coat
- Piston bores: 1.38 / 1.38 inches
- Piston type: Stainless
- Piston count: 4
- Published piston area: 3.00 square inches
- Dust boots: No
- Nominal rotor width: 0.38 inch
- Rotor thickness limits: 0.25–0.38 inches
- Rotor diameter limits: 10.00–13.06 inches
- Mounting style: Lug
- Handedness: Not restricted to one side; correct mounting and bleed orientation required
- Mounting centers: 5.25 inches
- Mounting-hole size: 0.39 inch
- Mount height: 2.10 inch
- Hydraulic inlet thread: 1/8-27 NPT
- Required pad shape: 7812
- Published pad area: 6.36 square inches
- Published pad volume: 2.1 cubic inches
- Manufacturer-listed component weight: 3.8 lb
Fitment & Compatibility
Verify the actual rotor thickness, diameter and centerline before checking bracket fit. Lug spacing and the 2.10-inch mount height must place the specified pads correctly on the friction track. Confirm wheel-spoke and inlet clearance, and avoid assuming that a similar caliper for a wider rotor is an equivalent replacement.
