Product details
This left-hand PS-1 is the 1.12-inch-bore version with an M10 x 1.25 hydraulic inlet. It has two opposed stainless pistons and a compact clear-anodized cast body. The metric inlet and mounting details should be checked explicitly when comparing it with an earlier or smaller-bore PS-1 installation. Based in Camarillo, California, Wilwood Engineering was founded by Bill Wood in 1977. The manufacturer produces disc brake systems and components for motorsport, street-performance and specialized applications, with a range covering calipers, brake rotors, master cylinders, valves, fittings and brake lines. Individual components are chosen to suit the complete brake system.
Technical Details
- Manufacturer part number: 120-8374
- Caliper type: PS-1
- Construction: Forged Aluminium
- Finish: Clear Anodize
- Piston bores: 1.12 inches
- Piston type: Stainless
- Piston count: 2
- Published piston area: 0.99 square inches
- Dust boots: No
- Nominal rotor width: 0.19 inch
- Rotor thickness limits: 0.15–0.20 inches
- Rotor diameter limits: 6.00–9.00 inches
- Mounting style: Lug
- Mounting side: Left Hand
- Mounting centers: 2.50 inches
- Mounting-hole size: 0.32 inch
- Mount height: 1.22 inch
- Hydraulic inlet thread: M10 x 1.25
- Required pad shape: 4108
- Published pad area: 2 square inches
- Published pad volume: 0.36 cubic inches
- Manufacturer-listed component weight: 1.1 lb
Fitment & Compatibility
Use the full drawing to confirm the mounting-hole thread, 2.50-inch centers and 1.22-inch mount height. Check rotor offset and pad sweep along with the diameter and thickness limits. The correct left-hand orientation must also leave access for bleeding and enough room for the hydraulic fitting inside the installed wheel.
