Product details
Red finish identifies this left-hand Narrow Superlite four-piston caliper. The selected unit uses booted aluminum pistons, a billet body and 5.98-inch radial mounting centers. It belongs to the 1.10-inch nominal rotor-width configuration and should be matched to its specific mounting and pad dimensions. Based in Camarillo, California, Wilwood Engineering was founded by Bill Wood in 1977. The manufacturer produces disc brake systems and components for motorsport, street-performance and specialized applications, with a range covering calipers, brake rotors, master cylinders, valves, fittings and brake lines. Individual components are chosen to suit the complete brake system.
Technical Details
- Manufacturer part number: 120-8062-LRD
- Caliper type: Billet Narrow Superlite 4
- Construction: Billet Aluminium
- Finish: Red Powder Coat
- Piston bores: 1.25 / 1.25 inches
- Piston type: Aluminum
- Piston count: 4
- Published piston area: 2.46 square inches
- Dust boots: Yes
- Nominal rotor width: 1.10 inch
- Rotor thickness limits: 1.00–1.10 inches
- Rotor diameter limits: 11.75–14.00 inches
- Mounting style: Radial
- Mounting side: Left Hand
- Mounting centers: 5.98 inches
- Mounting-hole size: 0.39 inch
- Mount height: 1.45 inch
- Hydraulic inlet thread: 1/8-27 NPT
- Required pad shape: 7416
- Published pad area: 8.2 square inches
- Published pad volume: 3.8 cubic inches
- Manufacturer-listed component weight: 5.0 lb
Fitment & Compatibility
Verify the installed rotor thickness against the exact part’s limits and compare its diameter and offset with the drawing. The left-hand orientation and 2.32-inch mounting height affect how the pads lie on the friction track. Check the NPT inlet, wheel clearance and brake balance rather than treating all narrow Superlite calipers as interchangeable.
PMB Performance has over 20 years of experience helping customers with brake and parts fitment. Share the installed component identification and relevant measurements when requesting assistance.
