Product details
Six staggered bores and a 7.48-inch lug pattern identify this black left-hand AeroDM front caliper. Wilwood lists it as a component of the documented Toyota Tundra conversion package. It is a forged hydraulic caliper with internal crossovers, intended to be matched to the package’s dedicated rotor and mounting arrangement. Based in Camarillo, California, Wilwood Engineering was founded by Bill Wood in 1977. The manufacturer produces disc brake systems and components for motorsport, street-performance and specialized applications, with a range covering calipers, brake rotors, master cylinders, valves, fittings and brake lines. Individual components are chosen to suit the complete brake system.
Technical Details
- Manufacturer part number: 120-18226-BK
- Caliper type: AeroDM Lug Mount
- Construction: Forged Aluminium
- Finish: Black Powder Coat
- Piston bores: 1.75 / 1.62 / 1.62 inches
- Piston type: Stainless
- Piston count: 6
- Published piston area: 6.52 square inches
- Dust boots: No
- Nominal rotor width: 1.25 inch
- Rotor thickness limits: 1.10–1.25 inches
- Rotor diameter limits: 12.19–13.56 inches
- Mounting style: Lug
- Mounting side: Left Hand
- Mounting centers: 7.48 inches
- Mounting-hole size: 0.40 inch
- Hydraulic inlet thread: 1/8-27 NPT
- Required pad shape: 6617
- Published pad area: 11.1 square inches
- Published pad volume: 5.2 cubic inches
- Manufacturer-listed component weight: 8.8 lb
- Documented front package: Toyota Tundra (2007–2015), Wilwood kit 140-18357; use the kit-specific rotor, line and hardware arrangement
- Matched-kit rotor: 1.26-inch thickness × 13.39-inch diameter in DS1695; identify the approved package by its exact component list
Fitment & Compatibility
Compare the existing or proposed kit with DS1695 before selecting the left side. The caliper’s nominal 1.25-inch rotor opening is a thickness specification and does not identify the kit’s rotor diameter. Use the installation drawing for centering, wheel clearance and fitting selection, and retain a master-cylinder setup suited to the complete six-piston system. The documented application is Toyota Tundra (2007–2015). The kit-specific rotor dimensions govern the matched assembly; do not treat the nominal caliper opening as approval for unrelated rotors.
