Product details
This anodized right front Wilwood TX6-DM is the 8.47-inch mounting-center configuration for the 2005–2012 Ford F-250/F-350 conversion. Six differential stainless pistons provide the selected 8.70-square-inch effective area in a forged aluminum housing. From its base in Camarillo, California, Wilwood Engineering designs and manufactures disc brake systems and components. Bill Wood founded the company in 1977; its motorsport, street-performance and specialized range includes calipers, brake rotors, master cylinders, valves, fittings and brake lines.
Technical Details
- Manufacturer part number: 120-17608. Type: TX6-DM Forged Lug Mount caliper.
- Nominal rotor width 1.50 inch; compatible width range 1.42–1.50 inch. Rotor diameter specification: 15.00 inches.
- 6-piston hydraulic layout with 2.00/1.88/1.88-inch bores and 8.70 sq in of effective area; piston type: stainless steel.
- Type III Anodize finish on a forged aluminum body.
- 8.47-inch-center lug attachment, right hand orientation.
- Compatible pad profile 10120; confirm thickness and compound for the installation.
- Hydraulic inlet thread: 1/8-27 NPT. Match the fitting thread and sealing arrangement to the brake hose.
- Piston dust boots: yes.
- Caliper component weight: approximately 14.1 lb.
- Component: one individual hydraulic brake caliper. Select the mating rotor, pads, mounting hardware and line connection to suit the complete brake assembly.
Fitment & Compatibility
Check whether the truck uses the 2005–2010 or 2011–2012 conversion package, since the specified hose arrangements differ. Match the Wilwood 15.00-inch rotor, spindle attachment and wheel-clearance drawing before replacing this caliper.
PMB Performance brings over 20 years of experience to brake-component selection. Share the installed caliper, rotor size and mounting arrangement so the relevant dimensions can be compared.
