Wilwood Front UTV4-C Anodized Four-Piston Brake Caliper, 0.25-Inch Rotor Width

This Wilwood UTV4-C is a front four-piston hydraulic caliper for the corresponding UTV brake arrangement. The anodized forged body uses four 1.25-inch stainless pistons, an M10 x 1.25 inlet and the nominal 0.25-inch rotor-width configuration. Bill Wood established Wilwood Engineering in 1977. Based in Camarillo, California, the company designs and manufactures disc brake systems for motorsport, street-performance and specialized use, including calipers, brake rotors, master cylinders, valves, fittings and brake lines.

Technical Details

• Manufacturer part number: 120-17546. Type: UTV4 Caliper caliper.
• Hydraulic inlet thread: M10 x 1.25. Match the fitting thread and sealing arrangement to the brake hose.
• Mounting: lug, 8.75-inch centers; orientation: universal.
• Piston arrangement: 4 stainless steel pistons; bore specification 1.25/1.25 inches. Effective piston area: 2.46 square inches.
• Rotor channel: 0.25-inch nominal width. Specified width limits: 0.19–0.25 inch; rotor outside diameter: 11.25 inches.
• Caliper body: forged aluminum; finish: Type III Anodize.
• Piston dust boots: no.
• Brake pad shape: 7812. Choose pad dimensions and friction material for the brake system.
• Caliper component weight: approximately 3.2 lb.
• Component: one individual hydraulic brake caliper. Select the mating rotor, pads, mounting hardware and line connection to suit the complete brake assembly.

Fitment & Compatibility

Match the exact UTV brake package, 8.75-inch radial pattern and rotor offset before ordering. The maximum rotor diameter is 11.25 inches, but model identity and mounting measurements must be confirmed for the actual vehicle rather than inferred from the general UTV designation.

For help matching this caliper, contact PMB Performance with the brake-package details and rotor measurements. Our team has more than 20 years of experience with brake parts and fitment.
