Wilwood Red Forged Dynapro LP Caliper, Four 1.38-Inch Stainless Pistons and Narrow Pad Sweep: Red Dynapro Low-Profile caliper showing the logo face, open top, wire retainers and dark mounting ears.

Wilwood Red Forged Dynapro LP Caliper, Four 1.38-Inch Stainless Pistons and Narrow Pad Sweep

SKU: 120-17460-RD

$282.25 Sale
Shipping calculated at checkout.

Fitment questions?

Call (855) 786-7101 or text (801) 304-3141.
Real people. Real answers.

Shipping policyRefund policy

Product details

Red powder coat surrounds the forged body of this Wilwood Dynapro Low-Profile caliper. Its four 1.38-inch pistons provide 3.00 square inches of effective area, while the low-profile bridge and top-retained pads address installations with restricted outboard space. Wilwood Engineering was founded by Bill Wood in 1977 and is based in Camarillo, California. The company designs and manufactures disc brake systems and components, including calipers, brake rotors, master cylinders, valves, fittings and brake lines for motorsport, street-performance and specialized applications.

Technical Details

  • Manufacturer part number: 120-17460-RD. Type: Forged Dynapro Lug Mount Low-Profile caliper.
  • Piston arrangement: 4 stainless steel pistons; bore specification 1.38/1.38 inches. Effective piston area: 3.00 square inches.
  • Rotor channel: 0.50-inch nominal width. Specified width limits: 0.44–0.50 inch; rotor outside diameter: 11.00–13.06 inches.
  • Mounting: lug, 5.25-inch centers; orientation: universal. 0.39-inch holes; 2.10-inch mounting height.
  • Hydraulic inlet thread: 1/8-27 NPT. Match the fitting thread and sealing arrangement to the brake hose.
  • Caliper body: forged aluminum; finish: Red Powder Coat.
  • Brake pad shape: 4812. Choose pad dimensions and friction material for the brake system.
  • Component: one individual hydraulic brake caliper. Select the mating rotor, pads, mounting hardware and line connection to suit the complete brake assembly.
  • Piston dust boots: no.
  • Caliper component weight: approximately 3.6 lb.

Fitment & Compatibility

Check both rotor sweep and hat clearance before choosing this caliper over a standard Dynapro. The bracket must locate the 4812 pads on the correct friction ring and maintain clearance to the wheel and inlet fitting.

PMB Performance has over 20 years of brake-component experience. Send the existing caliper identification, rotor measurements and mounting details for help comparing this configuration.
