Wilwood Right Anodized MC4 Mechanical Parking Brake Caliper, 0.25-Inch Rotor Width: Gray MC4 body above a gold-toned straight mounting bracket, with a large mechanical lever extending toward the upper right.

Wilwood Right Anodized MC4 Mechanical Parking Brake Caliper, 0.25-Inch Rotor Width

SKU: 120-17264

$171.56 Sale
Shipping calculated at checkout.

Fitment questions?

Call (855) 786-7101 or text (801) 304-3141. We check fitment by VIN.

Shipping policyRefund policy

Product details

This right-hand Wilwood MC4 applies a separate parking brake through a mechanical cable rather than a hydraulic hose. Its anodized body, 1.19-inch aluminum piston and 4.75-inch mounting bracket suit the nominal 0.25-inch rotor-width configuration. Founded in 1977 by Bill Wood, Wilwood Engineering is based in Camarillo, California. It designs and manufactures disc braking systems for motorsport, street-performance and specialized applications, with a component range covering calipers, brake rotors, master cylinders, valves, fittings and brake lines.

Technical Details

  • Manufacturer part number: 120-17264. Type: MC4 Mechanical caliper.
  • Brake pad shape: 6407. Choose pad dimensions and friction material for the brake system.
  • Caliper body: die-cast aluminum body with a forged aluminum anvil; finish: Type III Anodize.
  • Rotor channel: 0.25-inch nominal width. Specified width limits: 0.17–0.25 inch; rotor outside diameter: 11.00–14.00 inches.
  • Actuation: parking-brake cable with a 0.310-inch barrel end. Manual wear adjustment and a cable return spring are provided.
  • Mechanical piston count: 1. Bore: 1.19 inch; piston material: aluminum. Cable applied, with dust boot: yes.
  • Mounting: floating, 4.75-inch centers; orientation: right hand. 0.67-inch holes.
  • Caliper component weight: approximately 3.8 lb.
  • Assembly: one mechanical parking caliper, supplied with pads, noise-control shields and a steel mounting bracket. The service-brake system is separate.

Fitment & Compatibility

Match the mounting plate and cable pull to the vehicle's parking-brake layout. Check actual rotor width and diameter, and ensure the cable end, travel and return arrangement suit the lever; this caliper does not replace the hydraulic service brake.

Manufacturer warning, brake pads only: Cancer and Reproductive Harm. P65Warnings.ca.gov.

With 20+ years of experience, PMB Performance can help assess the brake hardware. Provide the caliper number, rotor dimensions and bracket measurements when asking about compatibility.
