Product details
The clear-anodized right Wilwood HE1 is an individual hydraulic and electric parking caliper. It combines a 4.75-inch attachment span with 1.25-inch piston bore; confirm the rotor centerline and 0.39-inch width configuration before installation. Based in Camarillo, California, Wilwood Engineering has its origins in the company Bill Wood founded in 1977. Its designs and manufactured disc brake products cover calipers and rotors alongside master cylinders, valves, fittings and lines. Motorsport, street-performance and specialized installations each require components selected for the complete system. The HE1 Hydra-Electric sliding caliper combines hydraulic actuation with an electric parking mechanism. Its single hydraulic piston, 1/8-27 NPT inlet and motor distinguish it from an electric-only EPB caliper. Both the hydraulic circuit and separate parking controls must be configured for the vehicle.
Technical Details
- Manufacturer part number: 120-17080
- Component: HE1 Hydra-Electric; one individual caliper
- Placement: Right
- Construction and finish: Cast aluminum; Clear Anodize
- Pistons: 1; stainless steel; bore dimensions 1.25 inches
- Hydraulic piston area: 1.23 square inches
- Dust boots: Yes
- Brake pad shape: 6407; shape number does not specify a friction compound
- Nominal rotor width: 0.39 inches
- Rotor width range: 0.15–0.39 inches
- Rotor diameter range: 11.00–14.00 inches
- Caliper weight reference: 4.7 lb
- Mounting interface: Floating; mounting centers 4.75 inches
- Mounting-hole diameter: 0.39 inches
- Hydraulic inlet thread: 1/8-27 NPT
One Hydra-Electric caliper. The rotor, hydraulic flexline, parking controller, switch, wiring and vehicle-specific mounting adapters are separate components.
Fitment & Compatibility
Confirm the 4.75-inch floating mount, the hydraulic line connection and clearance around the electric motor. The hydraulic service circuit and the parking controller are separate systems and both require a compatible installation. Controller, switch and wiring are not included as a complete kit.
