Product details
The 6.88-inch lug pattern identifies the attachment layout of this Wilwood AT6 Off-Road. This right-hand red caliper has 6 pistons, 1.75/1.38/1.38-inch bores and a 0.72-inch nominal rotor-width specification. Wilwood Engineering’s disc brake range includes calipers, rotors, master cylinders, valves, fittings and brake lines. Bill Wood founded the company in 1977 in California; it is based in Camarillo and serves motorsport, street-performance and specialized brake applications.
The AT6 six-piston racing caliper was developed for off-road trucks and buggies. A removable bridge gives top access to type 7516 pads, and the 6.88-inch lug pattern must align with the intended race upright or bracket.
Technical Details
- Manufacturer part number: 120-14850-RD
- Component: Wilwood AT6 Off-Road; one caliper
- Piston arrangement: 6 pistons; 1.75/1.38/1.38-inch bores; stainless steel
- Hydraulic piston area: 5.40 square inches, as specified by Wilwood
- Pad shape: Wilwood type 7516; compound selected separately
- Mounting: Right hand; Lug; 6.88-inch centers; 0.39-inch mounting holes
- Mount height: 2.62 inches
- Rotor width: 0.72-inch nominal; 0.66–0.72-inch permitted range
- Rotor diameter range: 12.30 inches
- Fluid inlet: 1/8-27 NPT
- Dust boots: No
- Body and finish: Forged aluminum; Red Powder Coat
Fitment & Compatibility
Measure the available space at both sides of the rotor, including its hat. Confirm mounting geometry and piston area; rotor width by itself cannot establish a complete brake package.
This listing covers one caliper. Match the brake pads, rotor, hose and mounting arrangement to the complete brake system.
