Product details
The 5.98-inch radial pattern identifies the attachment layout of this Wilwood Dynapro Radial Dust Seal. This Type III anodized caliper has 4 pistons, 1.25-inch bores and a 0.50-inch nominal rotor-width specification. Wilwood Engineering’s disc brake range includes calipers, rotors, master cylinders, valves, fittings and brake lines. Bill Wood founded the company in 1977 in California; it is based in Camarillo and serves motorsport, street-performance and specialized brake applications.
This four-piston radial Dynapro includes piston dust wipers. The radial mounting centers are common to several rotor-width and radius versions, so bracket height, pad sweep and actual rotor dimensions must all be compared.
Technical Details
- Manufacturer part number: 120-14698
- Component: Wilwood Dynapro Radial Dust Seal; one caliper
- Piston arrangement: 4 pistons; 1.25-inch bores; stainless steel
- Hydraulic piston area: 2.46 square inches, as specified by Wilwood
- Pad shape: Wilwood type 7816; compound selected separately
- Mounting: universal side configuration; Radial; 5.98-inch centers; 0.39-inch mounting holes
- Mount height: 1.61 inches
- Rotor width: 0.50-inch nominal; 0.38–0.50-inch permitted range
- Rotor diameter range: 10.75–12.19 inches
- Fluid inlet: 1/8-27 NPT
- Dust boots: Yes
- Body and finish: Forged aluminum; Type III anodized
Fitment & Compatibility
Measure the available space at both sides of the rotor, including its hat. Confirm mounting geometry and piston area; rotor width by itself cannot establish a complete brake package.
This listing covers one caliper. Match the brake pads, rotor, hose and mounting arrangement to the complete brake system.
PMB Performance’s team has over 20 years of experience with brake components and fitment. We can help review this caliper against the dimensions and hydraulic requirements of your brake system.
