Product details
The left front D8-6 brings a differential six-piston layout to stock-configuration 1965–1982 Chevrolet Corvette brakes. This anodized caliper uses D8 pads and the 1.88/1.38/1.25-inch stainless bore arrangement. Wilwood Engineering designs and manufactures disc brake systems for motorsport, street-performance and specialized applications. Bill Wood founded the company in 1977; it is based in Camarillo, California, and its component range includes calipers, brake rotors, master cylinders, valves, fittings and brake lines.
Technical Details
- Manufacturer part number: 120-11712. Component: D8-6 Caliper Front.
- Supply: one brake caliper, not a complete axle brake kit. Match the mating rotor, pads, bracket and connection hardware to the installation.
- The rotor channel is specified for 1.25-inch nominal width. Rotor outside diameter: 11.75 inches. Specified rotor-width limits: 1.17–1.25 inch.
- Hydraulic inlet thread: 1/8-27 NPT. Use a fitting with the correct thread and sealing seat.
- Brake pad profile D8; select friction material for the actual operating conditions.
- 7.00-inch lug mounting pattern, left hand; mounting height 1.83 inches.
- 6 stainless steel pistons with 1.88/1.38/1.25-inch bore groups. The specified effective area is 5.51 sq in.
- Piston dust boots: not fitted.
- Caliper weight: approximately 6.3 lb.
- Type III anodize finish on a forged aluminum caliper body.
Fitment & Compatibility
Respect the left-hand piston orientation and retain the specified stock rotor. Confirm 7.00-inch mounting centers, inlet-hose compatibility and clearance to the actual steel or alloy wheel.
