Wilwood Right Front Six-Piston D8-6 Caliper, Black / Corvette (1965–1982)

This black D8-6 is the right-hand front caliper for the original brake layout of a 1965–1982 Chevrolet Corvette. Its forged six-piston body preserves the specified front hydraulic volume while retaining D8 pad compatibility. Camarillo, California is home to Wilwood Engineering, the disc brake company Bill Wood founded in 1977. Its design and manufacturing range spans calipers, brake rotors, master cylinders, valves, fittings and brake lines for motorsport, street-performance and specialized brake systems.

Technical Details

• Manufacturer part number: 120-11711-BK. Component: D8-6 Caliper Front.
• Supply: one brake caliper, not a complete axle brake kit. Match the mating rotor, pads, bracket and connection hardware to the installation.
• Pad fit is type D8. Match the pad dimensions and compound to the rotor and intended braking conditions.
• Piston dust boots: not fitted.
• Bore configuration 1.88/1.38/1.25 inches across 6 pistons; piston material: stainless steel. Hydraulic effective area: 5.51 square inches.
• Nominal rotor width 1.25 inch; compatible outside diameter 11.75 inches. Specified rotor-width limits: 1.17–1.25 inch.
• Bracket interface: 7.00-inch lug centers with -inch holes. Specified mount height: 1.83 inches; orientation: right hand.
• Hydraulic inlet thread: 1/8-27 NPT. Use a fitting with the correct thread and sealing seat.
• Construction and surface: forged aluminum housing finished in Black powder coat.
• Caliper weight: approximately 6.3 lb.

Fitment & Compatibility

Confirm the right-hand differential bore arrangement and original front mounting geometry. Use the correct 1/8-27 NPT hose end, and check actual wheel clearance before choosing any required spacer.

Ask PMB Performance to check the complete brake arrangement before ordering. Our team brings over 20 years of experience; photographs and measured bracket and rotor dimensions make that check more useful.
